After reviewing 1000s of engineering drawings, you start to see the same failure modes on repeat: ambiguous intent, fragile datum schemes, tolerance gotchas, missing manufacturing context. The stuff that turns into re-quotes, shop questions, and surprise rework.
So we decided to encode those failure modes into MechPanda, a mechanical engineering copilot that redlines drawings for GD&T and DFM.
It’s simple:
Upload a drawing
MechPanda marks up issues with specific callouts
It suggests fixes to make the print more shop-ready (and easier to inspect)
Announcing MechPanda: GD&T + DFM redlines for your drawings
MechPanda exists to close a very specific gap: turning tribal knowledge into fast, repeatable feedback, so teams can move quicker without shipping ambiguity.
That’s also why we ran last week’s poll. We wanted a clearer picture of where drawings most often break down across design, manufacturing, and inspection, and to share the results back with the community.
Here’s the biggest takeaways from last weeks poll
One takeaway we can’t ignore: everyone agrees 2D drawings and compliance still matter, but GD&T confidence is all over the map.
Check out the complete poll results here.
GD&T confidence is mixed. Your drawing doesn’t have to be. Upload a print for GD&T + DFM redlines with exact fixes.
Happy Engineering,
The Drafter Team
